Pure 650 - Cast vs Core

[Strat-Supra]

I'm looking into upgrading my turbo with the Pure 650 cast version, I've seen discussions on the Pure 800 cast version causing overboost issues, but I've not been able to find (I've searched) similar discussions with the 650. Granted, not everyone enlarged their wastegate port or had to, either they didn't have an issue or fixed it in their tune.

Has anyone or is anyone aware of a similar issue with the 650?

My goal is ~500 whp without ethanol and ~550 with ethanol. I know new injectors or fuel system aren't required to achieve these numbers, but I'm wondering if there's any value in using S58 injectors?

Thanks in advance.

Sponsored



[Traxion]

I found no useful information when I was researching the Pure 650 before purchase. So far I am happy with my cast version and Razorlab hasn’t found any issues with tuning it so far. Based on his virtual dyno on tuning tools (which estimates high) I think I’m a little north of 500 with E30. I’m not sure if it can reach 500 on 93. Razorlab did mention S58 injectors would gain me a little more but I think that’s more relevant to ethanol mixes than 93.

My car will be dynod probably in November or December and I’ll be able to post an update somewhere here on the site.



[dAgent]

From the dynos I have seen you'll be slightly below 500 on 93 and also slightly below 550 on like e30-40. In good weather you might get those numbers though. I think I have seen maybe 3-4 dynos like that with the stock fuel system as I'm also interested in this turbo. If you mean cast as in what Pure calls "New" or their cast I've also heard a shop say they flow slightly better, but I don't know for sure if that's true? Is that what you meant? I think I've read the same over boost discussion on FB but I didn't realize they were talking about the "New" version specifically.



[Traxion]

From the dynos I have seen you'll be slightly below 500 on 93 and also slightly below 550 on like e30-40. In good weather you might get those numbers though. I think I have seen maybe 3-4 dynos like that with the stock fuel system as I'm also interested in this turbo. If you mean cast as in what Pure calls "New" or their cast I've also heard a shop say they flow slightly better, but I don't know for sure if that's true? Is that what you meant? I think I've read the same over boost discussion on FB but I didn't realize they were talking about the "New" version specifically.

Yes new = cast.



[Strat-Supra]

Thanks @Traxion, good to hear you've not had any issues.

I'm ok with slightly below 500 and 550, not dead set on those numbers.



[razorlab]

S58 injectors are so cheap now ($240/set) then it's kind of a no brainer if you want some more fueling headroom.

Pure650 will do 5XX no issue with the setup you are asking about.



[Razors Edge]

S58 injectors are so cheap now ($240/set) then it's kind of a no brainer if you want some more fueling headroom.

Pure650 will do 5XX no issue with the setup you are asking about.

Down to $133 per here….

https://xtreme-di.com/product/bmw-s58-oem-injector/



[Traxion]

Down to $133 per here….

https://xtreme-di.com/product/bmw-s58-oem-injector/

Why would someone want to pay more? That's $798/set at $133/each.

They run $40/each at $240/set on FCP Euro: https://www.fcpeuro.com/products/bmw-direct-fuel-injector-bosch-13538671991



[mojo_jojo77777]

Down to $133 per here….

https://xtreme-di.com/product/bmw-s58-oem-injector/

Thats expensive.
Razorlab was referring to ALL 6 for less than what you're posting

BMW Fuel injector Kit - 13538671991KT | FCP Euro



[Razors Edge]

Why would someone want to pay more? That's $798/set at $133/each.

They run $40/each at $240/set on FCP Euro: https://www.fcpeuro.com/products/bmw-direct-fuel-injector-bosch-13538671991

Oh shid, I thought he meant $240 each, which is what I saw usually. That’s even better!!



[razorlab]

Down to $133 per here….

https://xtreme-di.com/product/bmw-s58-oem-injector/

What a deal, you should jump on that.



[Strat-Supra]

S58 injectors are so cheap now ($240/set) then it's kind of a no brainer if you want some more fueling headroom.

Pure650 will do 5XX no issue with the setup you are asking about.

Thanks, gonna need your help to get there if you're willing and have time, no idea what the lead times are.



[razorlab]

Thanks, gonna need your help to get there if you're willing and have time, no idea what the lead times are.

I just ordered a Pure800 (non-recast version) and it took 3 weeks from ordering to ship date.



[Dr. Supra]

I found no useful information when I was researching the Pure 650 before purchase. So far I am happy with my cast version and Razorlab hasn’t found any issues with tuning it so far. Based on his virtual dyno on tuning tools (which estimates high) I think I’m a little north of 500 with E30. I’m not sure if it can reach 500 on 93. Razorlab did mention S58 injectors would gain me a little more but I think that’s more relevant to ethanol mixes than 93.

My car will be dynod probably in November or December and I’ll be able to post an update somewhere here on the site.

How do i access this virtual dyno?



[Traxion]

Register here and upload your logs in the files section then select virtual dyno on the left.
https://norcalmotorsports.org/logapp/portal.html
