Race Tracking Your Supra - Information exchange

3TMagnetMan

Well-Known Member
Joined
Jun 2, 2021
Threads
4
Messages
482
Reaction score
531
Location
New Jersey
Car(s)
2021 Supra 3.0 premium
Chassis limited function code. A friend of mine put on Sway bars and after the install he drove home he got the Code car drives fine would it be a problem on track day??
Sponsored



Traxion

Well-Known Member
Joined
Oct 6, 2021
Threads
1
Messages
225
Reaction score
343
Location
Southeast, USA
Car(s)
2022 Toyota Supra 3.0 Premium
Chassis limited function code. A friend of mine put on Sway bars and after the install he drove home he got the Code car drives fine would it be a problem on track day??
He probably knocked loose the ride height sensor. It's on the driver side wheel. Here's a view from the front of the car.



Here's how it's supposed to be attached. View from rear side. The clip is plastic so I zip tied mine in place as the clip would no longer hold.



3TMagnetMan

Well-Known Member
Joined
Jun 2, 2021
Threads
4
Messages
482
Reaction score
531
Location
New Jersey
Car(s)
2021 Supra 3.0 premium
He probably knocked loose the ride height sensor. It's on the driver side wheel. Here's a view from the front of the car.



Here's how it's supposed to be attached. View from rear side. The clip is plastic so I zip tied mine in place as the clip would no longer hold.

I wonder if I should get spare sensors just in case they break or snap.


Rta95

Well-Known Member
First Name
Rahat
Joined
Jul 13, 2022
Threads
8
Messages
138
Reaction score
80
Location
Somerset, NJ
Car(s)
2022 Toyota Supra 3.0 Premium
Chassis limited function code. A friend of mine put on Sway bars and after the install he drove home he got the Code car drives fine would it be a problem on track day??
Second question though for anyone, got a track day on Sunday and if I don't get this sorted by then would it be safe to track the car? Again car feels completely fine. Feels really good actually lol


Traxion

Well-Known Member
Joined
Oct 6, 2021
Threads
1
Messages
225
Reaction score
343
Location
Southeast, USA
Car(s)
2022 Toyota Supra 3.0 Premium
Second question though for anyone, got a track day on Sunday and if I don't get this sorted by then would it be safe to track the car? Again car feels completely fine. Feels really good actually lol
If it is the sensor yeah it's safe. I didn't get any limp modes on a few rowdy autocross runs before I figured out what it was.

I wonder if I should get spare sensors just in case they break or snap.
If you've got nothing else to spend ~$75 on and hate dash lights then go for it. It's the arm that is more likely to break. Looks like it's only $10. https://toyotaparts.bochtoyotasouth...xJmw9MiZuPVJlY29tbWVuZGVkIFByb2R1Y3RzJms9MQ==

Link for sensor: https://toyotaparts.bochtoyotasouth.com/oem-parts/toyota-level-sensor-89272waa01


Rensuhlo

Well-Known Member
First Name
Chuck
Joined
Nov 12, 2022
Threads
12
Messages
750
Reaction score
1,307
Location
Georgia
Car(s)
NA
I just snagged a set of CRS V1 in a 275-40 for $1k. They only need to last four events. Talk about "score" 👍🏻🤘🏼
Waiting on an invoice from PhD for some V1 CRS, Titan 7 TS-5s, spacers, and stud kit. 👍🏻🤘🏼

  • Like
Reactions: kaj

FLtrackdays

Well-Known Member
First Name
Mark
Joined
Mar 6, 2022
Threads
30
Messages
3,508
Reaction score
3,492
Location
the least restrictive State in the USA
Car(s)
2022 Supra 3.0, ND MX5 Club, VW GTI MK7.5
Second question though for anyone, got a track day on Sunday and if I don't get this sorted by then would it be safe to track the car? Again car feels completely fine. Feels really good actually lol
If it is the sensor yeah it's safe. I didn't get any limp modes on a few rowdy autocross runs before I figured out what it was.
My biggest fear was that the “nannies” would come on slowing me down or she’d go into limp mode. None of that ever happened. In fact it was just the opposite. You couldn’t turn them on. Which was great! Traxion is right. That thing is just floppy, looks and feels loose. But it’s just the way it is. My mechanic told me mine was completely normal. So now I pay a guy that’ll come to my house and can code out anything. Turns out a windshield installer has all the tech/computer tools to do so as well as a salvage yard guy.

(I no longer needed that particular code fixed after I got Ohlins and my ride height is now closer to normal - but I did code it out prior to that)

I just snagged a set of CRS V1 in a 275-40 for $1k. They only need to last four events. Talk about "score" 👍🏻🤘🏼
I did the same 😂 after I told myself I was going to buy v2. Then I saw the close out price, thank to the heads up from Rock!! Even Maxxis went up in price. So these were a no brainer

Last edited:

Rocksandblues

Well-Known Member
First Name
Bob
Joined
Sep 21, 2020
Threads
41
Messages
2,197
Reaction score
3,809
Location
Virginia
Car(s)
2021 Supra, e46 M3, diesel BMW e90, GL450
I just snagged a set of CRS V1 in a 275-40 for $1k. They only need to last four events. Talk about "score" 👍🏻🤘🏼
think you, Fl, and I got some of the last sets this week. My email already says “shipped”


Deighvid

Well-Known Member
First Name
Deighvid
Joined
May 25, 2021
Threads
19
Messages
667
Reaction score
738
Location
Los Angeles
Car(s)
2021 3.0 Supra Premium
I wonder if I should get spare sensors just in case they break or snap.
Someone makes a replacement bracket and arm for the sensor that's made out of AL and supposed to be stronger.

Anyone tried that and does it make a difference?


FLtrackdays

Well-Known Member
First Name
Mark
Joined
Mar 6, 2022
Threads
30
Messages
3,508
Reaction score
3,492
Location
the least restrictive State in the USA
Car(s)
2022 Supra 3.0, ND MX5 Club, VW GTI MK7.5
Someone makes a replacement bracket and arm for the sensor that's made out of AL and supposed to be stronger.

Anyone tried that and does it make a difference?
You know what… I did buy that 😂 It’s on there now. I figured what the hell, can’t hurt to have a beef 🥩 ier one. I got it from speed industry. I can look for this invoice if you have trouble finding it


baagel

Well-Known Member
Joined
Oct 22, 2021
Threads
17
Messages
430
Reaction score
455
Location
USA
Car(s)
2021 Supra 3.0 Premium, 2020 Challenger Hellcat
Someone makes a replacement bracket and arm for the sensor that's made out of AL and supposed to be stronger.

Anyone tried that and does it make a difference?
You know what… I did buy that 😂 It’s on there now. I figured what the hell, can’t hurt to have a beef 🥩 ier one. I got it from speed industry. I can look for this invoice if you have trouble finding it
I have it on my car, but only because I felt like it and not because there were problems.

https://www.viscontituning.com/products/a90-supra-rear-suspension-ride-height-sensor-bracket-upgrade

OP
OP
Todday1

Todday1

Well-Known Member
First Name
Tod
Joined
Aug 5, 2022
Threads
1
Messages
232
Reaction score
299
Location
Scottsdale
Car(s)
2021 A91 Supra
Here is a pic of the rear ride hight sensor. Is on left rear. Have to pull tire to get to it or have it up on a hoist. I expect when they changed the rear bar they could have broken this or pulled it off when they dropped sub frame.



razorlab

Well-Known Member
First Name
Bryan / Briana
Joined
Oct 2, 2021
Threads
23
Messages
4,744
Reaction score
9,503
Location
Your moms bedsheets
Car(s)
Not a Corvette.
Here is a pic of the rear ride hight sensor. Is on left rear. Have to pull tire to get to it or have it up on a hoist. I expect when they changed the rear bar they could have broken this or pulled it off when they dropped sub frame.

Yup, it's SUPER easy to break that grey plastic bit attached to the lower arm when doing suspension.
